AG-4 Liberty Aircraft specifications

  • Aircraft type: Electric or hybrid-electric VTOL aircraft with ducted fans
  • Pilots: 2
  • Passengers: 10
  • Cruise speed: 280 knots (322 mph, 519 km/h)
  • Horse power: 6,400 hp.
  • Motors: 4 electric motors. Each motor is a 3 phase AC induction motor rated at 1600 hp. (1200 Kw)
  • Ducted fans: 4
  • Propellers: 5 blade composite variable pitch (constant speed) propeller
  • Length: 41.12 ft. (12.53 m)
  • Height of Aircraft: 17.55 ft. (5.35 m)
  • Wingspan: 48.55 ft. (14.8 m)
  • Passenger cabin length: 11.15 ft. (3.4 m)
  • Passenger cabin width: 13.38 ft. (4.08 m)
  • Size of rear door: 32.6 sq. ft. (3.03 sq. m)
  • Entrance: Located at the rear of the aircraft for loading and unloading of passengers and crew
  • Empty weight: 10,320 lbs. (4,681 kg)
  • Payload weight: 2,000 lbs. (907 kg)
  • MTO weight: 12,500 lbs. (5,670 kg), MTO = Maximum take-off thrust
  • Wing type: Canard wing with rear high wing
  • Tail assembly: Twin tail
  • Landing gear: Wheeled tricycle retractable landing gear
  • Safety features: Ballistic parachute, Distributed Electric Propulsion (DEP)
